Brief introduction
Drilling buckets are mainly used for drilling water-bearing sandy
soil, sludge, clay, muddy sub clay, sandy gravel, cobble, and
weathered soft formation. The bucket can be designed into
cylindrical type and conical type according to bucket diameter,
type of drilling rig and soil conditions. The opening and closing
device can be operated manually, mechanically or mixed manner. The
welding angle of bucket teeth can be designed according to
formation conditions.
The bottom cover is made of high-strength Mn plate, and the cutting
edge includes single-layer type and double-layer type; The soil
inlet also includes single-bottom type and double-bottom type.
Our Service:
1. Prompt Delivery.
2. Best after-sale service.
3. The product could be produce according to customer”s
requirements.
4. Inquiries are typically replied within 24 hours.
Diameter:600~3000(mm)
Apply rock:Dense sand, granvle and medium up to weak
| Diameter (mm) | Bucket D1 (mm) | Height H (mm) | Bucket height H1 (mm) | Flat teeth N.O. | Bullet teeth NO. |
| 600 | 540 | 2000 | 1200 | 2 | 10 |
| 800 | 700 | 2000 | 1200 | 4 | 14 |
| 1000 | 900 | 2000 | 1200 | 6 | 18 |
| 1200 | 1100 | 2000 | 1200 | 7 | 20 |
| 1500 | 1400 | 2000 | 1200 | 9 | 28 |
| 1800 | 1700 | 2000 | 1000 | 11 | 32 |
| 2000 | 1900 | 1600 | 800 | 13 | 34 |
| 2200 | 2100 | 1600 | 800 | 15 | 36 |
| 2500 | 2400 | 1500 | 700 | 17 | 40 |
| 3000 | 2900 | 1500 | 700 | 21 | 46 |
|
|
